Product Features
Dual mode USB data output: The USB channel supports two upload modes for tag EPC data: HID keyboard analog output and GS1 standard code output. It can receive silver, inventory, and ledger software without the need for additional drivers;
Dual color status indicator: The green light is always on to indicate normal status, and it will flash during the RFID module inventory period; The red light indicates that the RFID module of the device is in an abnormal state;
Integrated industrial structure design: The whole machine has an integrated desktop shape, a flame‑retardant engineering plastic shell, and is compact and portable; Internal structure partition layout, reinforced interfaces to prevent loosening, static electricity, and collision, suitable for long‑term placement and use on office and warehouse desktops;
Compatible with upper computer communication: It can adapt to various types of PCs, industrial control computers, and terminal devices, with strong compatibility.
Performance parameters
Project
Parameter
Identification
Radio Frequency Identification (UHF RFID)
RFID Main Chip
Impinj E710 or domestic product
Frequency
902MHz~928MHz, Frequency bands can be customized
Communication
USB (HID default), USB‑to‑serial converter
Antenna
Array antenna
Power Input
DC5V,2A
Rated Power
≤10W
Ambient Humidity
Relative humidity: 5‑95% non‑condensing
Function
UHF RFID tag read and write operation
Air Interface Protocols
ISO 18000‑6C/B (EPC C1 G2)
Power
0‑30 dBm adjustable
Material
ABS face‑plate
Reading Distance
0‑30cm
Dimensions/Weight
33030016.5mm 1.0kg
Operating Temperature
-25℃‑+65℃
Storage Temperature
-40℃‑+85℃
